AXDIS-FD1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 11/22/24 INSTAXDIS-FD1
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (ex. butt-connectors, bell caps, etc.)
• Small flat-blade screwdriver
TABLE OF CONTENTS
Applications ...........................................................2
Connections ........................................................ 3-5
For models without a Sony/THX amplifier ........3
For models with a Sony/THX amplifier ..............4
3.5mm jack steering wheel control retention
.......5
Installation .............................................................5
Programming, Adjustments ................................. 6
Extra Features ........................................................ 7
Steering Wheel Control Settings ......................8-11
LED Feedback........................................................8
Changing Radio Type ...........................................9
Remapping ......................................................9-10
Dual Assignment Instructions ............................11
Troubleshooting....................................................12
Ford Data Interface with SWC 2006-2022
•
Designed for non-amplified & amplified models (including Sony/THX)
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains RSE (Rear Seat Entertainment)
• Retains SAT (Satellite Radio)
• Retains SYNC
®
• Retains the factory AUX-IN jack
• Retains balance and fade (excluding Sony/THX)
• Micro-B USB updatable
• AXDIS-FD1 interface
• AXDIS-FD1 harness
• 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
APPLICATIONS
See inside front cover
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
Product Info
www.MetraOnline.com
MetraOnline.com may be
used to assist with dash
assembly instructions.
Simply enter your Year,
Make, Model vehicle into
the vehicle fit guide and
look for the Dash Kit
Installation Instructions.
Visit AxxessInterfaces.com for up-to-date vehicle specific applications.
