AXDI-6524
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 5/16/24 INSTAXDI-6524
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties
TABLE OF CONTENTS
Connections ........................................................ 2-3
Installation .............................................................3
Programming .........................................................3
App Instructions .................................................4-5
Jeep/Ram Select Models Data Interface 2014-Up
• Designed for non-amplified systems
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (Retained Accessory Power)
•
Provides wires for multimedia radios (park brake, reverse, speed sense)
• Pre-wired AXSWC harness (AXSWC sold separately)
•
Retains the factory backup camera (Not retained on Wrangler JL
or Gladiator)
• Retains balance and fade
• Retains the factory AUX-IN jack
• Allows retention and adjustment of the Personalization Options
• Adjust Personalization Options through a wireless application
• Smartphone application offering full control from either Android
or Apple mobile devices
• Micro-B USB updatable
• AXDI-6524 interface
• LD-AX-XSVI-CH3BT Harness
• 2-pin CAN harness
OPTIONAL ACCESSORIES
(sold separately)
Steering Wheel Control Interface:
AXSWC OBD T-Harness: AX-IL-OBD2
APPLICATIONS
Jeep
Gladiator* ....................................................................................2020-Up
Renegade .................................................................................. 2015-2017
Renegade Sport ................................................................................. 2018
Wrangler* JL (Base model) .........................................................2018-Up
Ram
Promaster (w/color screen) .......................................................2014-Up
Promaster City .............................................................................2015-Up
* Factory Backup Camera will not be retained on Wrangler JL or Gladiator
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the
ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
Visit AxxessInterfaces.com for more detailed information about
the product and up-to-date vehicle specific applications
