Installation Instructions for AXBUCS-NI246V
Installation Instructions for AXBUCS-NI246V
Metra recommends MECP
certified technicians
Metra recommends MECP
certified technicians
Connections to be made
Connect the Black wire with a ring terminal to chassis ground.
Connect the Black wire of the AXCSD-6V wire to chassis ground.
Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire
of the AXCSD-6V.
Connect the Green/Purple wire to the reverse wire of the aftermarket radio,
and also to the Blue/White wire of the AXCSD-6V.
For all models except the Cube / Rogue, if retaining the factory AUX-IN jack,
connect the Red & White RCA jacks to the AUX input.
Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired AXSWC harness:
This harness is to be used along with the optional AXSWC (not included) to
retain steering wheel audio controls. Please refer to the AXSWC instructions
for radio connections and programming.
Note: Disregard the harness that comes with the AXSWC.
• Connect the unlabeled Red wire to the accessory wire.
Connections to be made
Connect the Black wire with a ring terminal to chassis ground.
Connect the Black wire of the AXCSD-6V wire to chassis ground.
Connect the Red wire labeled "Camera Power 6V" to the Blue/Red wire
of the AXCSD-6V.
Connect the Green/Purple wire to the reverse wire of the aftermarket radio,
and also to the Blue/White wire of the AXCSD-6V.
For all models except the Cube / Rogue, if retaining the factory AUX-IN jack,
connect the Red & White RCA jacks to the AUX input.
Connect the Yellow RCA jack to the rear camera input of the aftermarket radio
.
12-pin pre-wired AXSWC harness:
This harness is to be used along with the optional AXSWC (not included) to
retain steering wheel audio controls. Please refer to the AXSWC instructions
for radio connections and programming.
Note: Disregard the harness that comes with the AXSWC.
• Connect the unlabeled Red wire to the accessory wire.
Instrucciones de instalación para AXBUCS-NI246V
Metra recomienda técnicos
con certificación del Programa
de Certificación en Electrónica
Móvil (Mobile Electronics
Certification Program, MECP).
Conexiones que se deben hacer
Conecte el cable negro con una terminal de aro al tierra del chasís.
Conecte el cable negro del AXCSD-6V a tierra del chasís.
Conecte el cable rojo marcado con "Cámara de alimentación de 6V" a
el cable azul/rojo del AXCSD-6V.
Conecte el cable
verde/púrpura
al cable de reversa del radio de mercado
secundario y también para el cable
azul/blanco
de la AXCSD-6V.
Para todos los modelos excepto el Cubo / Rogue, si retener el enchufe AUX-
IN de fábrica, conecte los conectores RCA rojo y blanco al entrada AUX.
Conecte el conector RCA amarillo RCA en la entrada de la cámara de reversa del
radio de mercado secundario
.
Arnés AXSWC precableado de 12 pins:
Este arnés se debe usar junto con el AXSWC opcional (no incluido) para
retener los controles de audio en el volante. Consulte las instrucciones de
AXSWC para las conexiones del radio y la programación.
Nota: Ignore el arnés que viene con el AXSWC.
• Conectar el cable rojo marcado con el cable accesorio.
Instrucciones de instalación para AXBUCS-NI246V
Metra recomienda técnicos
con certificación del Programa
de Certificación en Electrónica
Móvil (Mobile Electronics
Certification Program, MECP).
Conexiones que se deben hacer
Conecte el cable negro con una terminal de aro al tierra del chasís.
Conecte el cable negro del AXCSD-6V a tierra del chasís.
Conecte el cable rojo marcado con "Cámara de alimentación de 6V" a
el cable azul/rojo del AXCSD-6V.
Conecte el cable
verde/púrpura
al cable de reversa del radio de mercado
secundario y también para el cable
azul/blanco
de la AXCSD-6V.
Para todos los modelos excepto el Cubo / Rogue, si retener el enchufe AUX-
IN de fábrica, conecte los conectores RCA rojo y blanco al entrada AUX.
Conecte el conector RCA amarillo RCA en la entrada de la cámara de reversa del
radio de mercado secundario
.
Arnés AXSWC precableado de 12 pins:
Este arnés se debe usar junto con el AXSWC opcional (no incluido) para
retener los controles de audio en el volante. Consulte las instrucciones de
AXSWC para las conexiones del radio y la programación.
Nota: Ignore el arnés que viene con el AXSWC.
• Conectar el cable rojo marcado con el cable accesorio.
