3
REV. 12/17/24 INSTAXAMP-CH3
ADDING AMPLIFIER/AMPLIFIERS TO A FACTORY SYSTEM
A
2-Pin
Connect 2 Pin if Amplified
LD-BASSKNOB
LD-BASSKNOB
20-Pin
LED
FRONT
REAR
SUB
2 PIN
20 PIN
TOSS
LINK
CHIME VOL
UPDATE
PORT
Interface
R
LD-PAW-CH3
LED
FRONT
REAR
SUB
2 PIN
20 PIN
TOSS
LINK
CHIME VOL
UPDATE
PORT
Interface
2-Pin
30
86
85
87
To 12v
Constant
2-Pin
RCA Jacks
(sold separately)
Not Used
If connecting multiple amps, Metra recommends incorporating
an SPDT Relay (not included). Metra SPDT Relay part #: E-123
SPDT Relay
If system is non-amplified, connect A to B.
Otherwise, refer to www.Metraonline.com for
available amplifier bypass harness and disreguard
connecters A, B and C from LD-PAW-*** harness.
8-Pin
Blue/White - Amp Turn-On Wire
FL
FR
RR
RL
LD-PAW-EXT
1 of 2
LD-PAW-EXT
2 of 2
B
C
Factory Radio
*BACK*
22-Pin
Factory Radio Harness
22-Pin
