A X ADCT- 4 A X ADCT- 4
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
A X ADCT- 4 A X ADCT- 4
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 4/27/20 REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
REV. 4/27/20 REV. 4/27/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifier Remote
Generator
The AXADCT-4 is designed to convert 4 channels of speaker level audio into 4 channels
of line level audio that can be used by OEM amplifiers. It can also be used with OEM
radios to add aftermarket amplifiers. This device will also detect the presence of an
audio signal and then generate a +12V output (verified by an illuminated LED) that can
be used to turn-on an aftermarket amplifier.
Features & Specifications: The AXADCT-4 is able to handle 80 watts per channel
continuous input without over heating. The input circuitry is designed to correct the
crossover distortion commonly found on standard LOCs while providing a high to low
level step down of 6:1. Output audio level is infinitely adjustable using the onboard,
high quality potentiometers. The remote output or amplifier trigger is rated at 500mA
(+12V) and will easily handle an outboard relay if additional current is needed. The
remote output will trigger instantaneously when the AXADCT-4 detects a DC voltage
on the white, left + audio input wire above 5V or a very low audio signal. It will shut
off 60 seconds after no signal is detected.
Installation: The AXADCT-4 should be installed on a stereo’s speaker output wires or
the output wires on an OEM amplifier of up to 80 watts per channel. These wires can
be found behind the stereo in the dash, on the output of an OEM amplifier, or on the
input terminals on the OEM speakers. Please refer to the wiring diagram for the input
connection details.
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifier Remote
Generator
The AXADCT-4 is designed to convert 4 channels of speaker level audio into 4 channels
of line level audio that can be used by OEM amplifiers. It can also be used with OEM
radios to add aftermarket amplifiers. This device will also detect the presence of an
audio signal and then generate a +12V output (verified by an illuminated LED) that can
be used to turn-on an aftermarket amplifier.
Features & Specifications: The AXADCT-4 is able to handle 80 watts per channel
continuous input without over heating. The input circuitry is designed to correct the
crossover distortion commonly found on standard LOCs while providing a high to low
level step down of 6:1. Output audio level is infinitely adjustable using the onboard,
high quality potentiometers. The remote output or amplifier trigger is rated at 500mA
(+12V) and will easily handle an outboard relay if additional current is needed. The
remote output will trigger instantaneously when the AXADCT-4 detects a DC voltage
on the white, left + audio input wire above 5V or a very low audio signal. It will shut
off 60 seconds after no signal is detected.
Installation: The AXADCT-4 should be installed on a stereo’s speaker output wires or
the output wires on an OEM amplifier of up to 80 watts per channel. These wires can
be found behind the stereo in the dash, on the output of an OEM amplifier, or on the
input terminals on the OEM speakers. Please refer to the wiring diagram for the input
connection details.
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifier Remote
Generator
The AXADCT-4 is designed to convert 4 channels of speaker level audio into 4 channels
of line level audio that can be used by OEM amplifiers. It can also be used with OEM
radios to add aftermarket amplifiers. This device will also detect the presence of an
audio signal and then generate a +12V output (verified by an illuminated LED) that can
be used to turn-on an aftermarket amplifier.
Features & Specifications: The AXADCT-4 is able to handle 80 watts per channel
continuous input without over heating. The input circuitry is designed to correct the
crossover distortion commonly found on standard LOCs while providing a high to low
level step down of 6:1. Output audio level is infinitely adjustable using the onboard,
high quality potentiometers. The remote output or amplifier trigger is rated at 500mA
(+12V) and will easily handle an outboard relay if additional current is needed. The
remote output will trigger instantaneously when the AXADCT-4 detects a DC voltage
on the white, left + audio input wire above 5V or a very low audio signal. It will shut
off 60 seconds after no signal is detected.
Installation: The AXADCT-4 should be installed on a stereo’s speaker output wires or
the output wires on an OEM amplifier of up to 80 watts per channel. These wires can
be found behind the stereo in the dash, on the output of an OEM amplifier, or on the
input terminals on the OEM speakers. Please refer to the wiring diagram for the input
connection details.
A 4 Channel Adjustable, Line Output Converter (LOC) with Built-in Amplifier Remote
Generator
The AXADCT-4 is designed to convert 4 channels of speaker level audio into 4 channels
of line level audio that can be used by OEM amplifiers. It can also be used with OEM
radios to add aftermarket amplifiers. This device will also detect the presence of an
audio signal and then generate a +12V output (verified by an illuminated LED) that can
be used to turn-on an aftermarket amplifier.
Features & Specifications: The AXADCT-4 is able to handle 80 watts per channel
continuous input without over heating. The input circuitry is designed to correct the
crossover distortion commonly found on standard LOCs while providing a high to low
level step down of 6:1. Output audio level is infinitely adjustable using the onboard,
high quality potentiometers. The remote output or amplifier trigger is rated at 500mA
(+12V) and will easily handle an outboard relay if additional current is needed. The
remote output will trigger instantaneously when the AXADCT-4 detects a DC voltage
on the white, left + audio input wire above 5V or a very low audio signal. It will shut
off 60 seconds after no signal is detected.
Installation: The AXADCT-4 should be installed on a stereo’s speaker output wires or
the output wires on an OEM amplifier of up to 80 watts per channel. These wires can
be found behind the stereo in the dash, on the output of an OEM amplifier, or on the
input terminals on the OEM speakers. Please refer to the wiring diagram for the input
connection details.
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
