2
CONFIGURATION
• Download and install the Axxess Updater available at: AxxessInterfaces.com
• Connect the AXUSB-MCBL update cable (sold separately) between the interface and the computer.
The cable will connect into the micro-B USB port in the interface.
• Open the Axxess Updater and wait until the word Ready is listed in the bottom left of the screen.
• Select Add-Cam Configuration.
Continued on the next page
INTRODUCTION
The AXAC-CH7 is a camera switching interface that provides:
• A front camera, and/or side cameras that an be added to the factory radio.
• Up to (3) additional camera inputs to the factory radio, while still retaining the factory camera.
• Automatic camera function, no human interaction is required, unless desired.
• Up to (4) cameras, if the vehicle doesn’t come equipped with a backup camera.
Note: Axxess recommends cameras from the iBEAM product line for best results.
OEM CAMERA RETENTION
JEEP
Wrangler JL/JT ............................................................... 2018.5-2023
RAM
11500/2500/3500 Classic.................................................2019-2023
ADD CAMERAS TO FACTORY RADIO (w/uConnect Radio)
JEEP
Gladiator ............................................................................2020-2023
Wrangler JL .................................................................... 2018.5-2023
RAM
1500(DT) ............................................................................2019-2021
1500 Classic ..................................................................... 2019-2023
APPLICATIONS
