4
CONFIGURATION (CONT.)
Video trigger legend
• Disable (will turn off the input)
• Backup Camera (dedicated backup camera)
• Left Blinker (will be used for activation)
• Right Blinker (will be used for activation)
• Control 1 (positive trigger activation)
• Control 1 (negative trigger activation)
• Control 2 (positive trigger activation)
• Control 2 (negative trigger activation)
• Control 3 (positive trigger activation)
• Control 3 (negative trigger activation)
• Control 4 (positive trigger activation)
• Control 4 (negative trigger activation)
• Auto (Reverse -> Drive) will activate once
that sequence is seen (only available for
video trigger 4)
Video trigger description
• Reverse camera: Dedicated by default to Video Trigger 1. Will activate the backup camera
while the vehicle is in reverse.
• Left blinker: Activation of the left turn signal will activate the left camera.
• Right blinker: Activation of the right turn signal will activate the right camera.
•
Auto (reverse -> drive): Available only for Video Trigger 4, when installing a front camera.
With this feature selected, the camera will activate automatically once a reverse-then-drive
sequence is seen from the vehicle. Example of this scenario would be while parallel parking the
vehicle. As an alternative, a control wire can be used instead to manually activate the camera
.
Note:
Auto (Reverse -> Drive) will disable the camera once 15 MPH is reached. A control wire
activated will also disable the camera.
Note:
If the control wire is activated while driving, the camera will activate and deactivate
during stop-and-go traffic.
• Control 1-4 (positive or negative) trigger activation wires: Can be used as a positive or
negative trigger to manually activate a camera via a toggle switch, or similar device.
Other Settings
Switched 12v with
• Disable: Turns off the 12v from the
camera 12v (Red) wire
• Accessory Out: Accessory Out:
