7
REV. 7/3/25 INSTAXABH-LX1
CONNECTIONS
Yellow/Brown Front Left Speaker (+)
Green/Purple Front Left Speaker (-)
Green/Orange Front Left Tweeter (+)
Green/Red Front Left Tweeter (-)
Black/Yellow Rear Right Speaker (+)
Black/Green Rear Right Speaker (-)
White Rear Left Speaker (+)
White/Black Rear Left Speaker (-)
Gray Front Right Tweeter (+)
Gray/Black Front Right Tweeter (-)
Purple Front Right Speaker (+)
Purple/Black Front Right Speaker (-)
Toyota Prius 2016-Up
Yellow/Brown Rear Left Woofer (+)
Green/Purple Rear Left Woofer (-)
Blue Front Right Speaker (+)
Blue/Black Front Right Speaker (-)
Green/Orange Front Left Tweeter (+)
Green/Red Front Left Tweeter (-)
Black/Yellow Rear Left Speaker (+)
Black/Green Rear Left Speaker (-)
White Rear Right Speaker (+)
White/Black Rear Right Speaker (-)
Gray Front Right Tweeter (+)
Gray/Black Front Right Tweeter (-)
Green Front Left Speaker (+)
Green/Black Front Left Speaker (-)
Purple Rear Right Woofer (+)
Purple/Black Rear Right Woofer (-)
Toyota RAV4 2013-Up
Yellow/Brown Front Left Woofer (+)
Green/Purple Front Left Woofer (-)
Blue
Front Right Instrument Panel Speaker (+)
Blue/Black
Front Right Instrument Panel Speaker (-)
Green/Orange Rear Left Tweeter (+)
Green/Red Rear Left Tweeter (-)
Black/Yellow Rear Left Speaker (+)
Black/Green Rear Left Speaker (-)
White Rear Right Speaker (+)
White/Black Rear Right Speaker (-)
Gray Rear Right Tweeter (+)
Gray/Black Rear Right Tweeter (-)
Green Front Left Instrument Panel Speaker (+)
Green/Black Front Left Instrument Panel Speaker (-)
Purple Front Right Woofer (+)
Purple/Black Front Right Woofer (-)
Toyota Prius 2012-2015
