4
CONNECTIONS
Yellow/Brown Front Right Door Speaker (+)
Green/Purple Front Right Door Speaker (-)
Blue Front Left Door Speaker (+)
Blue/Black Front Left Door Speaker (-)
Green/Orange Subwoofer 1 (+)
Green/Red Subwoofer 1 (-)
Black/Yellow Subwoofer 2 (+)
Black/Green Subwoofer 2 (-)
White Rear Right Door Speaker (+)
White/Black Rear Right Door Speaker (-)
Gray Rear Left Door Speaker (+)
Gray/Black Rear Left Door Speaker (-)
Green Right Side Tweeter (+)
Green/Black Right Side Tweeter (-)
Purple Left Side Tweeter (+)
Purple/Black Left Side Tweeter (-)
Subaru Forester 2019-Up
Yellow/Brown Subwoofer (+)
Green/Purple Subwoofer (-)
Blue Front Right Tweeter (+)
Blue/Black Front Right Tweeter (-)
Green/Orange Center Speaker (+)
Green/Red Center Speaker (-)
Black/Yellow Left Front Door Speaker (+)
Black/Green Left Front Door Speaker (-)
White Right Front Door Speaker (+)
White/Black Right Front Door Speaker (-)
Gray Front Left Tweeter (+)
Gray/Black Front Left Tweeter (-)
Green Left Rear Door Speaker (+)
Green/Black Left Rear Door Speaker (-)
Purple Right Rear Door Speaker (+)
Purple/Black Right Rear Door Speaker (-)
Subaru Legacy / Outback 2015-Up
Green/White Front Left Speaker (+)
White/Red Front Left Speaker (-)
Brown/Yellow Rear Left Speaker (+)
Brown/Blue Rear Left Speaker (-)
Pink Rear Right Speaker (+)
White/Blue Rear Right Speaker (-)
Brown/White Rear Right Woofer (+)
Blue/Pink Rear Right Woofer (-)
Yellow/Brown Rear Left Woofer (+)
Green/Purple Rear Left Woofer (-)
Blue Rear Left Deck Speaker (+)
Blue/Black Rear left Deck Speaker (-)
Green/Orange Rear Right Deck Speaker (+)
Green/Red Rear Right Deck Speaker (-)
Black/Yellow Front Left Tweeter (+)
Black/Green Front Left Tweeter (-)
White Front Right Tweeter (+)
White/Black Front Right Tweeter (-)
Gray Center Channel (+)
Gray/Black Center Channel (-)
Purple Front Right Speaker (+)
Purple/Black Front Right Speaker (-)
Toyota Avalon 2013-2018
