AXABH-LX1
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 7/3/25 INSTAXABH-LX1
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Amplifier locations ................................................2
Connections
Lexus .................................................................... 3
Subaru ..............................................................3-4
Toyota ............................................................... 4-7
Amplifier Bypass Harness
Fits Select Lexus/Subaru/Toyota
2001-2023
Refer to the following pages for the vehicle specific instructions for
wiring connections. Wiring connections vary per vehicle.
If uncertain whether the vehicle contains a specific speaker or not,
test the wires with a tone generator, or check to see if the factory
wires are populated on the vehicle side. Alternatively, the wires can
be tested for impedance with a multimeter.
APPLICATIONS
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
ATTENTION: With the key out of the ignition, disconnect
the negative battery terminal before installing this
product. Ensure that all installation connections,
especially the air bag indicator lights, are plugged in
before reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
FEATURES
• Vehicle-specific harness to bypass the factory amplifier
• Saves the installer unnecessary labor and wire
• 20 gauge wires
• Wire Length: 12”
Lexus
ES-Series ......................2007-2012
ES-Series
(with Multi Disc) ........ 2002-2006
GS-Series .....................2001-2005
IS-Series ....................... 2013-2022
RX-Series ....................2004-2008
SC-Series ......................2002-2010
Subaru
Ascent .......................... 2019-2022
Crosstrek ......................2016-2022
Forester........................2016-2022
Impreza ....................... 2015-2022
Legacy .......................... 2015-2022
Outback........................ 2015-2022
WRX .............................2016-2022
Toyota
Avalon (Amplified) ...... 2015-2019
Avalon (w/NAV) ........... 2011-2014
Camry........................... 2018-2023
Camry (Amplified) ....... 2014-2017
Highlander
(Excluding 12” screen) ...
2020-2023
Highlander (Amplified) ... 2014-2019
Mirai ..............................2016-2019
Toyota (cont.)
Prius (Amplified) .........2016-2019
Prius (Plug-In) .............2012-2015
Prius V (Amplified) ...... 2013-2018
RAV4 ............................2019-2023
RAV4 (Amplified) .........2015-2018
