5
REV. 6/6/25 INSTAXABH-CH4
CONNECTIONS (CONT.)
Dodge
Viper 2015-2017
Green Left Rear Speaker +
Green/Black Left Rear Speaker -
Purple Right Rear Speaker +
Purple/Black Right Rear Speaker -
Orange Subwoofer 1 +
Orange/Black Subwoofer 1 -
Red Subwoofer 2 +
Red/Black Subwoofer 2 -
Yellow Center Instrument Panel Speaker +
Yellow/Black Center Instrument Panel Speaker -
Black Subwoofer 3 +
Black/White Subwoofer 3 -
Brown Subwoofer 4 +
Brown/Black Subwoofer 4 -
Blue NOT USED
Blue/Black NOT USED
22-Pin harness:
Jeep
Cherokee
†
2014-2020
Gladiator 2020-2024
Wrangler (JL body type) 2018-2024
Green Left Rear Speaker +
Green/Black Left Rear Speaker -
Purple Right Rear Speaker +
Purple/Black Right Rear Speaker -
Orange Subwoofer Coil #1 +
Orange/Black Subwoofer Coil #1 -
Red Subwoofer Coil #2 +
Red/Black Subwoofer Coil #2 -
Yellow Left Rear Tweeter +
Yellow/Black Left Rear Tweeter -
Black Right Rear Tweeter +
Black/White Right Rear Tweeter -
Brown Subwoofer Coil #3 +
Brown/Black Subwoofer Coil #3 -
Blue Subwoofer Coil #4 +
Blue/Black Subwoofer Coil #4 -
22-Pin harness:
†
With Active Noise Control (ANC)
