Je bekijkt pagina 3 van 8
3
REV. 6/6/25 INSTAXABH-CH4
CONNECTIONS
Chrysler
300* 2015-2023
Dodge
Charger* 2015-2023
Ram
1500 (excluding Classic)** 2022
Green Left Rear Door Speaker +
Green/Black Left Rear Door Speaker -
Purple Right Rear Door Speaker +
Purple/Black Right Rear Door Speaker -
Orange Left Rear Speaker +
Orange/Black Left Rear Speaker -
Red Right Rear Speaker +
Red/Black Right Rear Speaker -
Yellow Center Instrument Panel Speaker +
Yellow/Black Center Instrument Panel Speaker -
Black Right Rear Tweeter +
Black/White Right Rear Tweeter -
Brown Left Rear Tweeter +
Brown/Black Left Rear Tweeter -
Blue Subwoofer +
Blue/Black Subwoofer -
22-Pin harness:
* With Premium amp
** With Premium Plus amp
Chrysler
Pacifica 2017-2022
Green Left Rear Speaker/Tweeter+
Green/Black Left Rear Speaker/Tweeter -
Purple Right Rear Speaker/Tweeter+
Purple/Black Right Rear Speaker/Tweeter
Orange Left Rear Speaker+
Orange/Black Left Rear Speaker -
Red Right Rear Speaker+
Red/Black Right Rear Speaker -
Yellow Center Instrument Panel Speaker+
Yellow/Black Center Instrument Panel Speaker -
Black Rear Tweeter+
Black/White Rear Tweeter -
Brown Subwoofer 1+
Brown/Black Subwoofer 1 -
Blue Subwoofer 2 +
Blue/Black Subwoofer 2 -
22-Pin harness:
