AXABH-CH4
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 06/06/25 INSTAXABH-CH4
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Amplifier locations ................................................2
Connections
22-Pin Harness ................................................3-6
10-Pin Harness ....................................................7
APPLICATIONS
Chrysler
300 ........................... 2015-2023
Pacifica .....................2017-2022
Dodge
Challenger ............... 2015-2023
Charger .................... 2015-2023
Durango ...................2021-2022
Viper..........................2015-2017
Voyager ............................ 2022
Jeep
Cherokee..................2014-2020
Compass ........................... 2022
Gladiator ................. 2020-2024
Grand Cherokee ..........2014-2022
Wrangler JL .............2018-2024
Ram
Ram 1500 (exclude Classic) .. 2022
Ram 2500 (exclude Classic) .. 2022
Ram 3500 (exclude Classic) .. 2022
* Excluding Jeep Wrangler
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections, especially the air
bag indicator lights, are plugged in before
reconnecting the battery or cycling the
ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
Refer to the following pages for the vehicle specific instructions for wiring connections. Wiring connections vary per vehicle. Please note that
there are (2) different wiring harnesses included, and the instructions for each harness will be on a different page.*
If it’s uncertain whether the vehicle contains a specific speaker or not, test the wires with a tone generator, or check to see if the factory wires
are populated on the vehicle side. Alternatively, the wires can be tested for impedance with a multimeter.
Amplifier Bypass Harness
Fits Select Chrysler Models 2014-UP
FEATURES
• Vehicle-specific harness to bypass the factory amplifier
• Saves the installer unnecessary labor and wire
• 20 gauge wires
• Wire Length: 12”
Visit AxxessInterfaces.com for more detailed
information about the product and up-to-date
vehicle specific applications.
