5
REV. 6/03/2025 INSTAXABH-CH2
CONNECTIONS (CONT.)
DODGE
Dart 2013-2016
JEEP
Compass 2017-2021
Purple/White To Right Rear Door Speaker -
Red/White NOT USED
Purple To Subwoofer 2+
Gray/Blue
†
To Right Rear Speaker +
Yellow/Blue
†
To Left Rear Speaker -
Green/Black To Subwoofer 1 -
Orange To Right Front Speaker+
Pink To Left Front Speaker +
White/Purple To Right Rear Door Speaker+
White/Red NOT USED
Purple/Black To Subwoofer 2 -
Gray/Red
†
To Right Rear Speaker -
Yellow/Red
†
To Left Rear Speaker +
Green To Subwoofer 1 +
Orange/Black To Right Front Speaker -
Pink/Black To Left Front Speaker -
Black 16-Pin harness:
CHRYSLER
200 2015-2017
DODGE
Journey 2011-2020
Purple/White To Right Rear Speaker -
Red/White NOT USED
Purple To Subwoofer 2+
Gray/Blue To Right Rear Door Speaker +
Yellow/Blue To Left Rear Door Speaker -
Green/Black To Subwoofer 1 -
Orange To Right Front Speaker+
Pink To Left Front Speaker +
White/Purple To Right Rear Speaker+
White/Red NOT USED
Purple/Black To Subwoofer 2 -
Gray/Red To Right Rear Door Speaker -
Yellow/Red To Left Rear Door Speaker +
Green To Subwoofer 1 +
Orange/Black To Right Front Speaker -
Pink/Black To Left Front Speaker -
Black 16-Pin harness:
† These are tweeters in the Compass
