REV. 6/03/2025 INSTAXABH-CH2
CONNECTIONS (CONT.)
CHRYSLER
Town & Country 2008-2020
DODGE
Grand Caravan 2008-2020
Nitro 2007-2011
JEEP
Liberty 2008-2012
Wrangler JK 2007-2017
Purple/White To Subwoofer 3 -
Red/White To Right Rear Tweeter -
Purple To Subwoofer2 +
Gray/Blue To Right Rear Speaker +
Yellow/Blue To Left Rear Speaker -
Green/Black To Subwoofer 1 -
Orange To Right Front Speaker +
Pink To Left Front Speaker +
White/Purple To Subwoofer 3 +
White/Red To Right Rear Tweeter +
Purple/Black To Subwoofer2 -
Gray/Red To Right Rear Speaker -
Yellow/Red To Left Rear Speaker +
Green To Subwoofer 1 +
Orange/Black To Right Front Speaker -
Pink/Black To Left Front Speaker -
CHRYSLER
300 (Base Amp) 2011-2014
DODGE
Charger (Base Amp) 2011-2014
Gray/Black To Right Instrument Panel Speaker -
White/Black To Left Instrument Panel Speaker -
Green To Center Instrument Panel Speaker +
Gray To Right Instrument Panel Speaker +
White To Left Instrument Panel Speaker +
Green/Black To Center Instrument Panel Speaker -
Brown NOT USED
Brown/Black NOT USED
Black 16-Pin harness:
White 22-Pin harness:
