AXABH-CH2
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/03/25 INSTAXABH-CH2
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink
• Tape • Wire cutter • Zip ties
TABLE OF CONTENTS
Connections
White 22-Pin Harness ..................................... 2-3
Black 16-Pin Harness.......................................3-6
Refer to the following pages for the vehicle specific
instructions for wiring connections. Wiring connections
vary per vehicle. Please note that there are (2) different
wiring harnesses included, and the instructions for each
harness will be on a different page.
If it’s uncertain whether the vehicle contains a specific
speaker or not, test the wires with a tone generator, or
check to see if the factory wires are populated on the
vehicle side. Alternatively, the wires can be tested for
impedance with a multimeter.
APPLICATIONS
Chrysler
200 ..................................2015-2017
300 (Base Amp) .............2011-2014
Town & Country ...........2008-2020
Dodge
Charger (Base Amp) ......2011-2014
Dart .................................2013-2016
Durango .........................2014-2020
Grand Caravan .............2008-2020
Journey .......................... 2011-2020
Nitro ................................2007-2011
Jeep
Compass .........................2017-2021
Grand Cherokee
(Base Amp) ................. 2011-2013
Liberty ............................2008-2012
Wrangler JK ...................2007-2017
Ram
1500/2500/3500 ............. 2013-2021
Amplifier Bypass Harness
Fits Select Chrysler Models 2007-2023
FEATURES
• Vehicle-specific harness to bypass the factory amplifier
• Saves the installer unnecessary labor and wire
• 20 gauge wires
• Wire Length: 12”
Visit AxxessInterfaces.com for more detailed
information about the product and up-to-date
vehicle specific applications.
