AX-LOC2.2 & AX-LOC2.4
INSTALLATION INSTRUCTIONS
MetraOnline.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 5/8/23 INSTAX-LOC2.2 & AX-LOC2.4
TABLE OF CONTENTS
Quick Start Guide
Things to Know .................................................2
Connections ....................................................... 2
Gain setup
Basic setup .........................................................3
Advanced Setup ................................................ 3
Feature Breakdowns .............................................4
Quick Reference: AX-LOC2.2 ..................................5
Diagram: AX-LOC2.2...............................................6
Quick Reference: AX-LOC2.4 .................................7
Diagram: AX-LOC2.4 ..............................................8
Specifications .........................................................9
Universal Premium LOC
AX-LOC2.2 2 IN - 2 OUT with Max Input 20v
AX-LOC2.4 2 IN - 4 OUT with Max Input 20v
TOOLS RECOMMENDED
• Digital Multi-meter
• Test Tones
Universal Premium LOCs
The Axxess AX-LOC2.2 & AX-LOC2.4 can be used to add amplifiers to an audio system that does not have RCA outputs or when replacing an OEM
radio and retaining the factory amplified system. Variable Gain Controls with Clipping Indicators, Selectable Ground Isolation and Load Select
features ensure a pure, noise-free signal for any type of audio system.
AX-L0C2.4
AX-LOC2.4
Line Out Converter (LOC)
COMPONENTS
AX-L0C2.2
AX-LOC2.2
Line Out Converter (LOC)
