2
THINGS TO KNOW
1. This is an active LOC and MUST have constant 12 volt and a good ground to operate properly.
Having a poor ground can induce noise into your system, use the same gauge wire as the
12 volt line.
2. Determine a suitable mounting location. Make sure you can access all controls and
connections.
3. When ready to mount your LOC, check under your selected mounting location to make sure
it is clear of any wiring harnesses, fuel or brake lines, or anything else that may affect the
vehicle safety.
QUICK START GUIDE
CONNECTIONS
1. Connect your 12 volt and ground wires to the terminals. 14-16 gauge wire is recommended.
2. By default the LOCs Turn On Mode is set to DC Offset. Other turn on options are available
and described in the Turn On Signal Feature Breakdown portion of this manual.
3. Connecting your Speaker Input can happen in a few different places based on your factory
system.
a. If your vehicle doesn’t have an OE amplifier your best option is to use the speaker wires
located behind the radio. Your LOC only requires two inputs, we recommend a left
and right signal full range signal.
b. If your vehicle has an OE amplifier your best option is to use the speaker wires on
the output side of your factory amplifier, look for a full range signal.
4. Find a suitable mounting location of the Bass Knob and run the control wire to that location
in the vehicle. The Bass Knob included offers a voltage display and control of Bass Output
levels.
5. Connect your RCAs. Red RCAs are for the right channel. Black, Gray, or White are for the left
channels. An explanation of the RCA’s Main Output and Bass Output are described in the
Feature Breakdown portion of this manual.
