FEATURE BREAKDOWNS

Turn On Signal

Audio Sense – When selected the LOC will power up when an audio signal is present, regardless

of source. If the radio is muted and the LOC doesn’t see an audio signal, it will turn off.

DC Signal Sense (Default) – Detects when the OE radio or OE amplifier turns on. The AX-BRC-PRO

detects the DC voltage across the speaker leads and will provide 12 volts to the REM

OUT.

REM IN – This is the standard way to turn off aftermarket equipment by using a dedicated amp turn on signal or a true ignition signal. When the REM IN is powered it will output through the

REM OUT.

Ground Isolation Settings – Different types of ground noise can easily enter into your audio system. The Ground Isolation switch on the LOC will help eliminate some of the most common ground

noises with the simple flip of a switch.

GND – The ground for the LOC is tied to the ground shield of the audio signal.

ISO – The ground of the LOC and ground shield of the RCA are separated.

200

– LOC ground and ground shield of RCA are connected to each other by a 200

resistor, balancing yet isolating the ground circuit.

Load Select Settings – Factory radios and amplifiers can sometimes stop passing audio when they do not see the original speaker’s impedance. This is a common issue found in many Chrysler

vehicles. The load selector switch will offer two Ohm Load settings that will make the factory equipment think the original speakers are still connected and start passing audio. In some Chrysler

vehicles you will need to let the vehicle go the sleep (turn ignition off for 2 minutes) after each load selection.

20 ohm – Commonly used in vehicles that do not have a factory amplifier. Mainly late model Chrysler vehicles, which includes RAM, JEEP, DODGE, and some FIATS

60 ohm – Commonly used in vehicles with a factory amplifier. Mainly late model Chrysler vehicles, which includes RAM, JEEP, DODGE, and some FIATS

20k ohm – Default setting and used for all other applications.

If none of these Ohm load settings restore the factory audio or if you have distortion Proscenium offers additional load resistors that plug directly into the speaker level input terminal(s) of each

LOC AX-LR39 is the only value not built into the Axxess LOCs.
