2
THINGS TO KNOW
1.
This is an active LOC and MUST have constant 12volt and a good ground to operate properly.
Having a poor ground can induce noise into your system, use the same gauge wire as
the 12 volt line.
2. The AX-BRC-PRO gives you two audio input options: 2-channel speaker-level inputs and
2 channels of line level or RCA inputs. These choices enable you to connect your audio
sources effectively.
a. Speaker-Level Inputs: For devices like OE radios or amplifiers, opt for speaker-level
inputs. They can handle input signals ranging from 4Vrms to 40Vrms. Perfect for
maintaining compatibility with different setups.
b. RCA (Low-Level) Inputs: If you’re using sources other than OE radios or amplifiers,
RCA inputs are your go-to. These inputs accept signals within the range of 1Vrms to
10Vrms, ensuring adaptability to various audio devices.
3. Remote Level Control Jack: This RJ45 jack is for connecting the remote level control to
the main unit with the supplied cable.
QUICK START GUIDE
1. Connect your 12 volt and ground wires to the terminals. 14-16 gauge wire is recommended.
2. By default the LOC’s Turn on mode is set to DC offset. Other turn on options are available
and described in the Turn on Signal Feature Breakdown portion of this manual.
3. If using your SPEAKER Level Inputs there are a few different places to get audio into your
LOC based on your factory system.
a. If your vehicle doesn’t have an OE amplifier your best option is to use the speaker
wires located behind the radio. Your LOC only requires two inputs, we recommend a
left and right signal full range signal.
b. If your vehicle has an OE amplifier your best option is to use the speaker wires on
the output side of your factory amplifier, look for a full range signal.
4. If adding the AX-BRC-PRO to your aftermarket radio to improve your bass levels us the
RCA outputs from the aftermarket radio plugging into the LINE IN of the LOC.
5. Connect your RCA’s. Red RCA’s are for the right channel. Black, Gray, or White RCA’s are
for the left channels to your aftermarket amplifier.
6. It is recommend that the included bass knob be installed where the customer can reach
it easily. The bass knob will give them the ability to control the output levels of the
AX-BRC-PRO.
CONNECTIONS
