AX-ADXSVI-GM3

METRA. The World’s best kits.

™

metraonline.com1-800-221-0932

© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION

WIRING THE AX-ADXSVI-GM3

• ConnecttheYellowwiretotheradio’s12voltbatteryormemorywire.

• ConnecttheBlackwiretotheradio’sgroundwire.

• ConnecttheRedwiretotheignitionwireoftheaftermarketradio.

• ConnecttheOrange wiretotheilluminationwireoftheaftermarketradio.Ifthe

aftermarketradiohasnoilluminationwire,tapeofftheOrange wire.

• TheOrange/White wirewillnotbeusedinthisapplication.Tapeuporcapoff

thiswireanddisregardit.

• ConnecttheBluewiretotheantennaturnonwireoftheaftermarketradio.

• ConnecttheWhitewiretotheleftfrontpositivespeakeroutputofthe

aftermarketradio.

• ConnecttheWhite/Blackwiretotheleftfrontnegativespeakeroutputofthe

aftermarketradio.

• Connectthe Gray wiretotherightfrontpositivespeakeroutputofthe

aftermarketradio.

• ConnecttheGray/Blackwiretotherightfrontnegativespeakeroutputofthe

aftermarketradio.

• ConnecttheGreen wiretotheradio’sleftrearpositivespeakeroutput.

• ConnecttheGreen/Blackwiretotheradio’sleftrearnegativespeakeroutput.

• ConnectthePurplewiretotheradio’srightrearpositivespeakeroutput.

• ConnectthePurple/Blackwiretotheradio’srightrearnegativespeakeroutput.

Thefollo

wingwiresarefortheaftermarketradiosthathavenavigationbuiltin.

• ConnecttheLight Greenwiretotheparkingbrakewireoftheaftermarketnavigation

radio(ifapplicable).

• Connectthe Blue/Pink wiretotheVSSorspeedsensewireoftheaftermarket

navigationradio(ifapplicable).

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

IMPORTANT WARNING

Thisproductincludesinstructionsforinstallationwhichmustbecarefullyfollowed.The

instructionsarewordedinsuchamannertoassumethattheinstalleriscapableof

completingthesetypeofelectronicinstallations.Ifyouareunclearastowhatyouare

instructed to do or believe that you do not understand the instructions so as to properly

and safely complete the installation you should consult a technician who does have this

knowledge and understanding.

Failure to follow these instructions carefully and to install the interface as described

could cause harm to the vehicle or to safety systems on the vehicle. Interference with

certain safety systems could cause harm to persons as well. If you have any questions

in this regard please call the Help line or Metra at 1-800-221-0932 for assistance.

• ConnecttheGreen/Purplewiretothereversewireoftheaftermarketnavigation

radio(ifapplicable).

• Cyclethekey,byturningtheignitiononfor30seconds.Thenoffandonagainto

testtheradio.

ASWC-1 (if installing)

AftertheXSVIisinitialized,plugintheASWC-1intothe12-pinharnessofthe

AX-ADXSVI-GM3andrefertotheASWC-1instructions.
