SHARK S8X PLUS
8CH Video Switcher
30
Note: The A/B interface outputs are two connectors of the same signal.
13.2.Multiview Output
The default output of the multiview port is multiview. Users can connect it to a larger size display, which
can be configured through the menu to output other source signals including PGM, clean broadcast
signals without downstream keyed caption logos, and various input source signal outputs.
13.3.PGM Output
The factory default is to output the PGM program broadcast screen. The menu can be configured to
output other source signals including multi-screen, clean broadcast signal without downstream key
subtitle logo and various input source signal output.
13.4.LCD Output
The video switcher's LCD output supports multiview mode and PGM mode.
By pressing the MV button on the panel, users can quickly switch between the multiview and the currently
selected screen on the LCD (such as PGM).
Note: When MV switches to PGM, if an interface chooses to output multiview, it will also switch to PGM
full-screen.
13.5.USB Output
When the user connects the USB output to the PC, the user can use software such as OBS, PotPlayer,
VMix, etc. to play or capture the USB output video and audio on live platforms such as YouTube,
Facebook, Twitter, etc. USB3.0 streaming output is based on UVC (USB video class) and UAC (USB
audio class) standards. No additional drivers need to be installed. The relevant video and audio devices
will be automatically detected and displayed in the Windows Device Manager:
• imaging devices: Switcher Capture
• Audio Inputs and Outputs: Switcher Capture
In addition, the USB video source can be not only PGM output, but also IN1-IN8. PVW, PGM, Clean PGM,
Color Bar output. Users can set up, capture and stream the video they need.
