SHARK S8X PLUS
8CH Video Switcher
27
Mask Top
0%-100%
0
Mask Right
0%-100%
0
Mask Bottom
0%-100%
0
11.2.LOGO
The switcher allows users to import logos. Press the menu button to select the logo settings interface.
Users can select a logo from the media pool on a USB Disk, and set its position, size, and opacity.
Rotate the menu knob to select a logo, then press the menu knob to select and delete the logo.
Logo format support: JPG，PNG，BMP，JPEQ，PBM，IPS，MPO
Logo size support: 10×10 pixel to 650×650 pixel
LOGO button ON：LOGO shows on PVW.
ON AIR button ON：LOGO shows on PGM
ON AIR and LOGO button both ON：DSK available on both PVW and PGM. Corresponding status in
menu is <KEY & ON AIR>
Menu
Sub-Menu
Item
Parameter
Default
DSK
Logo
Logo status
OFF/ KEY (PVW)/ ON AIR (PGM)/ KEY &
ON AIR
Off
Logo Selection
/
Horizontal
Position
0%-100%
98%
Vertical
Position
0%-100%
2%
Scale Ratio
0.5-1.5
1.0
Opacity
0-100
100
