SHARK H4M
四通道音视频切换台
33
When the indicator of button in Part A is on in green means the corresponding audio is on. When the
indicator is off means the corresponding audio is off.
Taking the image as an example, after pressing the IN1 button, the indicator of IN 1 keeps blinking, while
the indicator of AUDIO ON button is green and the indicator of AFV button is green, i.e., audio of IN1 is on
and AFV of IN1 is off.
After pressing one Part A button, the indicator of button in Part B is on in green means the corresponding
audio function is on. When the indicator is off means the corresponding function is off.
13.5.2.Audio Configuration Steps
Step 1. Press one button from Part A to select the audio for configuration, the LED indicator of the button
will keep flashing, which means it is available to make configuration.
Step 2. Press AUDIO ON button from Part B to turn on the audio, then LED indicator turns to green, and
press AFV button to set the audio following video, and LED indicator turns green. Press the AUDIO ON/
AFV double times to turn it off and indicator turns off too. Press button VOL+/ VOL- to adjust the audio
volume. Note: AFV button is not available for MASTER.
Step 3. The selected button from Part A in Step 1 is still flashing, press it again to finish the configuration
and the indicator stops flashing. Or when Part A button is flashing press another button from Part A to
select the next audio to configurate it in the same way, and when finish all configuration of audio, press
again the flashing button from Part A to finish all configuration and stop the flashing indicator.
13.5.3.Mute
The switcher has a MUTE button in the row of PVW keyboard. It is quick and easy for user to press the
button to make the Master audio turn off. When MUTE turns on the LED indicator keeps flashing which
means the PGM audio is being mute. Besides, the speed of MUTE can be set from menu (Refers to Part
11.12)
14.Media Library
14.1.PVW Pattern & PGM Pattern
This switcher PVW and PGM can be set to customized patterns. The PVW and PGM pattern source can
be selected from black FTB/color bar/color 1/color 2/ IN1/IN2/IN 3/IN 4/Image.
