SHARK H4M
四通道音视频切换台
32
audio is set to AFV mode, then the audio will be turned on only when the PGM switches to this channel
video source.
For example, IN 1 audio is set to AFV mode, the IN 1 embedded audio will be turn on only when the
switcher switch HDMI 1 as the video source of PGM.
13.4.Audio Delay
In the menu there is an audio delay setting for IN1, IN 2, IN 3, IN 4, Mixer. User can adjust the audio delay
to make the audio and video synchronization. The audio can be delayed by a maximum of 500ms.
13.5Audio Keyboard Configuration
The audio not only can be configured by the menu but also can be configured by the keyboard control of
the switcher. The keyboard includes two parts as below image.
Part A is for selecting one audio to be configured,
including Master, MIC 1,INI 1,IN 2, IN 3 and IN 4.
Part B is for setting audio functions, including
AUDIO ON, AFV, VOL+ and VOL-.
13.5.1 Audio Indicator
