SHARK H4M
四通道音视频切换台
8
4.Volume knob for the microphone input channel
Adjusts the final volume of the channel signal in the overall mix.
5.Volume adjustment for audio input channels 7-8 and 9-10 and PGM
MP3&AUXPress this button, CH9-10 channel is AUX audio input, pop up
this button, it is MP3 player/USB sound card audio input, with CH9-10
knob you can adjust the volume of the channel. When the signal reaches
-10dbu the SIG indicator starts to flash.
CH9-10 AUX IN: 3.5mm TRRS audio auxiliary input interface.
CH7-8 VOL Knob: Adjust the volume of audio input channels 7-8. When
the signal reaches -10dbu, the SIG indicator starts to flash.
CH9-10 VOL Knob: Adjust the volume of audio input channels 9-10.
When the signal reaches -10dbu, the SIG indicator starts to flash.
PGM VOLKnob: Adjust the volume of the mixer's audio and video audio
mixes sent to the main outputs so that the SIG indicator begins to flash
when the signal reaches -10dbu.
6.Bluetooth Audio Receiver Pairing Button&Volume adjustment for
Bluetooth audio
PAIR: Bluetooth Audio Receiver Pairing Button
Short press the button, the bluetooth receiver enters the search state, this
button blinks quickly; after connecting successfully, the button is long light;
When the Bluetooth receiver is playing, the button blinks slowly.
When the Bluetooth receiver is playing or paused, short press the button
to turn off the Bluetooth receiver, the button does not light up, long press
the button to clear the current connection and re-enter the search state,
Bluetooth receiver name: Video Switcher.
BT PLAYER VOL Knob: The BTPLAYER VOL knob adjusts the final
volume of the Bluetooth audio receiver signal in the total mix. The SIG
indicator begins to flash when the signal reaches -10dbu.
