13
PGM In: Receive the TALLY program signal from the video switcher.
PGM Out: Output the TALLY signal to the currently controlled PTZ camera.
Note: When PGM out is selected, the For PGM option in the Follow menu is not available.
2） Signal Follow：Options: Off, For PGM or For PVW.
For PGM: Select this option, the controller will synchronize the corresponding PTZ camera according to
the PGM camera signal source selected by the video switcher.
For PVW: Select this option, the controller will synchronize the corresponding PTZ camera according to
the PVW camera signal source selected by the video switcher.
4.2.3 RESET Setting
There are 2 options: Reset preference and Factory Reset.
Factory Reset: It will clear all keyboard settings of the PTZ camera controller, and restore to factory
default.
Reset Preference: It can retain the currently saved camera connection configuration information and
User configuration information such as camera preset position and PTZ speed.
TALLY
Indicator
Name
Color
Status
Description
PGM signal
input
(referring to the
switcher’s
program signal)
Red
Lamp On
When receiving the PGM in
signal from the video switcher,
the tally area on the touch
screen will light up red.
Lamp Off
No signal
PVW Signal In
(Referring to
the switcher’s
preview signal)
Green
Lamp On
When receiving the PVW signal
from the video switcher, the
tally area on the touch screen
will light up green
Lamp Off
No signal
