⑨ RS422 Interface
When using RS422 to connect multiple cameras, connect the RS422 IN to the RS422 OUT
interface of the previous camera, and connect the RS422 OUT to the RS422 IN interface
of the next camera. For specific pin definitions, see "3.3 S422 Interface Description"
⑩ RS232 Interface
When using RS232 to connect multiple cameras, connect the RS232 IN to the
RS232 OUT interface of the previous camera, and connect the RS232 OUT to
the RS232 IN interface of the next camera. For specific pin definitions, see "3.2
RS232 Interface Description".
⑪ 12G-SDI Interface
The image signal is output in the SDI video signal format, and the dual- SDI
interfaces are output simultaneously.
This
interface can support with a maximum resolution of 3840*2160@60fps.
⑫ HDMI2.0 Interface
Using the HDMI video signal format to output the image signal.
⑬ 3.5mm Audio Input
3.5mm dual-channel universal audio input interface, which can be connected
to the audio output interface of a microphone or other audio players. The
input audio signal can be output simultaneously through network stream, UAC,
HDMI, SDI etc.
⑭ USB3.0 Type-B Interface
Using UVC or UVC+UAC to output the video and audio signal.
⑮ LAN Interface
The maximum bandwidth is 1000M, which is used for network communication
and Stream or POE+ power.
⑯ DC12V Power Interface
DC12V Input, connect to external power adapter(provide)
4K Ultra HD PTZ Camera
