Operating instructions
EVOLUTION PC 3.3/ 5.3
10
2.3. Filter
The PC 3.3/ 5.3 have both DC filtering and HF filtering. The filtering is described in more detail below.
2.3.1.
DC-Filter
In the PC 3.3 and PC 5.3, the neutral mains cable is connected to the externally connected devices
via a capacitance of 50,000μF. This blocks any DC voltage from the mains up to 2.4 V. The capacitors
are protected against overvoltage by two rectifiers that can withstand up to 35 amps.
DC test button
Press the DC test button (3) to bypass the DC filter on all mains sockets. If there is a strong direct
current at the mains input of the device, you will hear the mains transformers of the connected
devices (e.g. power amplifiers with large transformers) humming. When you release the button, the
hum disappears again thanks to the built-in DC filter.
2.3.2.
HF-Filter
Each individual socket of the PC 3.3 & PC 5.3 is equipped with a differential choke and filter
capacitors between N and L as well as between earth and N / earth and L. This filters common mode
and unbalanced RF interference. This filters common mode and unbalanced RF interference.
HF test button
Pressing the HF test button (5) bypasses the interference filter on the left mains output (with PC5.3:
only on the lower output). This allows you to compare the sound of a connected source with and
without HF filtering.
2.3.3.
Acoustic function test
If you press the "MONITOR" button (4), the built-in loudspeaker gives you an impression of the
incoming RF interference.
By pressing it a second time, the loudspeaker outputs the filtered, outgoing RF interference. It is easy
to hear that the interference is drastically reduced.
2.4. Remote control functions (RC 3/ RC 5)
You can switch the power conditioner on and off by pressing the ON and OFF buttons on the AVM
RC3 /RC5 IR remote control.
Before switching to standby mode, the display shows a 10-second countdown and allows you to
cancel the action by pressing "ON" on the remote control again.
NOTE:
The IR function can be activated/deactivated by pressing and holding the button in the middle
below the display and then switching on the power supply (switch on the back).
The display shows the current setting:
• IR ON: "ACTIVE"
• IR OFF: "PASSIVE"
