Pairing-Prozess

Option B: via the DSP PC-Tool software

1. Connect the DSP / DSP amplier to your PC and launch the DSP PC-Tool software.

2. Go to the “Extension Card Settings” tab in the “Device” menu and click “Pair”. The Info LED of the Extension Card 2.0

will now ash alternately blue and red.

3. Open the Bluetooth

settings on your device and connect to the “ATF BT HD” network. A successful pairing is indicat-

ed by the Info LED ashing blue once every two seconds.

Option C: via a connected remote control

Pairing mode can also be started via a remote control connected to the DSP device, such as the CONDUCTOR or

DIRECTOR.

1. Start the pairing process via the remote control:

- DIRECTOR: Go to the “Bluetooth

Connect” menu and push the “Pair” button.

- CONDUCTOR: Switch to a “Volume Control” or “Bluetooth

Playback” control menu and press the rotary knob for

more than 5 seconds.

Further information on the pairing function of the remote control can be found in the corresponding user manual.

2. Open the Bluetooth

settings on your device and connect to the “ATF BT HD” network. A successful pairing is indicat-

ed by the Info LED ashing blue once every two seconds.

DigitalopticaloutputoftheExtensionCard2.0–BTHD

The installation of the Extension Card 2.0 adds as well an additional digital optical SPDIF output to your device. This

output allows to transmit any unprocessed input or DSP-processed output signals to other devices.

The digital output delivers an uncoded stereo PCM signal with either 96 kHz / 24 bit or 48 kHz / 24 bit, depending on the

sampling rate of the designated DSP device.

The routing can also be congured in the DSP PC-Tool software under “Digital Output Routing” in the “Signal Manage-

ment (IO)” section of the “Routing” tab.
