Je bekijkt pagina 42 van 106
www.audibax.com 40
M88 DSP / M88 DSP Dante
Open central control command window and click parameters to be controlled on
interface, then the window will display current command immediately. Copy the
command and then use UDP or RS232 to send the command to devices.
(2) Device upgrade
Device upgrade can be carried out through UDP. Connect the device, click
setting-help-device upgrade. A file choice box will be popped up at this point, and then
choose processor upgrade file (*.bin).
(3) About
Display version number, tech support contact information and copyright info., etc.
Among the options that can be assigned to each master button we will have:
Volume:
We can assign any audio input or output available on the unit, assign a name to the
function, and the maximum and minimum volume range to program.
Button:
Mute function of an input, output or general channel
Preset:
Assign a working memory (up to 16 selectable)
Command:
Assign control commands, UDP, RS232 or RS485, to send commands to other units
connected to the NexusX ecosystem
Matrix:
Preset source assignment, you can assign any type of crossover within the connected
matrix options as well as different types of combinations available
Once the adjustment or assignment has been completed within the panel, and with all
units in Network, press the "Uploadpanell" icon to send the entire scene to the assigned
panel.
Help menu
(1) Central command
