Velocity
131
Custom Control Interface
DSP Mute
To create a DSP Mute button, select Add DSP Mute from either the Panel Widgets on the left navigation or the drop
down menu in the screen eld.
Once a control has been added to the edit screen area, select the square and the properties menu will appear on the
right side.
NOTE: The DSP Mute button
will display icons by status. No
icon will display on the page edit
screen.
Control Links
• Control Device - Select the audio device that has already been added and
set up in the room or variable value (new values will show up with the selection of
Variable Value).
• Control Channel - Choose the audio channel from the drop down menu.
Only channels already in the audio driver will appear.
• Icon Switch - Select if the eld controls muting audio (Mute Audio) or turning
lights on/o (Light Switch).
• On/O Color - Set the eld colors that will display when Audio is muted
(on) or not muted (o).
Label and Label Text Position
• Type - Select between Text, Variables, or Data Source.
◊ Text - Type the control name in the Value eld.
◊ Variables - Select a variable from the drop down. See Variables section
for creation of custom variables.
◊ Data Source - Set the label to pull from a specic row or column of a
specied hosted CSV le.
