AT-USB-EX350-KIT
13
Device Operation
RS-232 Control
Connect an RS-232 cable from the RS-232 port on the AT-USB-EX350-DV to a device that will be controlled via a
serial connection, such as a camera. This connection will be established over the network using a TCP Proxy to the
AT-USB-EX350-HS.
GND
To serial-controlled device
TX
RX
}
PWR
1 2 3
USB DEVICES (5G)
4
RS-232
AT-USB-EX350-DV
RX TX
DEBUGHDBT-USB3
LINK FW
48V
1.36A
PWR
1 2 3
USB DEVICES (5G)
4
RS-232
AT-USB-EX350-DV
RX TX
DEBUGHDBT-USB3
LINK FW
48V
1.36A
