AT-UHD-CLSO-840
9
The Atlona AT-UHD-CLSO-840 is a 4K/UHD 8×4 matrix switcher for HDMI and HDBaseT with eight inputs, four
discrete outputs, audio integration capabilities, and Ethernet-enabled 100 meter HDBaseT extension with PoE
remote device powering. It is ideal for presentation environments with content on multiple displays, as well as
videoconferencing, presentation capture, and divisible rooms.
The CLSO-840 supports resolutions up to 4K/UHD at 60 Hz with 4:2:0 chroma subsampling. Ethernet pass-through
allows HDBaseT Ethernet extension from a control system or network. Audio system integration is streamlined with
audio embedding and de-embedding, dedicated input and output gain controls, and a ve-band EQ for each output.
The CLSO-840 is congured and managed using Atlona Management System software to simplify installation and
enable remote monitoring and support.
Introduction
Features
Package Contents
• 8×4 matrix switcher with HDBaseT and HDMI inputs and outputs
• 4K/UHD capability @ 60 Hz with 4:2:0 chroma subsampling
• Extended distance HDMI extension
• 8×4 audio matrix switching for de-embedded audio
• HDMI audio embedding
• PoE power source – remotely powers PoE-compatible transmitters and receivers
• HDCP 1.4 compliant
• EDID management
• HDCP management
• TCP/IP and RS-232 control
• IP to RS-232 translation
• Multichannel audio
• Front panel button controls and LCD menu display
• Rack mountable 2U, full-rack width enclosure
1 x AT-UHD-CLSO-840
8 x Captive screw connector, 5-pin
1 x Captive screw connector, 3-pin
1 x IEC C13 power cable
2 x Mounting ears
1 x Installation Guide
