AT-UHD-CAT-4
12
Device Operation
The LED indicators on both the front of the unit provide basic information on the current status of the AT-UHD-CAT-4.
LED Indicators
LED Description
POWER Blue Unit is powered and in normal operating mode.
Red Unit is in standby mode.
• Press the POWER button to place the unit in normal operating mode.
Off Unit is not powered.
• Check the power supply and make sure it is securely fastened to the
locking connector on the rear of the unit.
• Make sure that the power supply is connected to an available electrical
outlet and that the outlet is “live” (some outlets are controlled by a wall
switch).
HDMI
IN / OUT
Blue IN: Source is connected to the HDMI IN port.
OUT: Sink device is connected to the HDMI OUT port.
Off IN: No source device connected to the HDMI IN port.
OUT: No sink device is connected to the HDMI OUT port.
• Check the integrity of the HDMI cable; make sure a secure connection
exists between the HDMI port on the AT-UHD-CAT-4 and the source/
display device.
• Try a dierent HDMI cable.
HDBaseT
1 - 4
Blue Normal operation. Signal integrity between the AT-UHD-CAT-4 and the
connected receiver is good.
Off No connection between the HDBaseT port on the AT-UHD-CAT-4 and the
receiver unit.
• Check the Ethernet cable for a secure connection.
• Possible bad cable; try a dierent Ethernet cable.
LOCK Blue Front-panel buttons on the AT-UHD-CAT-4 are locked. Refer to the API or
Locking the Front Panel (page 13) for more information.
Flashing Blue The number of ashes indicate whether the unit is in DHCP or static IP
mode. Refer to IP Conguration (page 10) for more information.
Off Front-panel buttons on the AT-UHD-CAT-4 are unlocked.
INT Blue AT-UHD-CAT-4 is using the internal EDID. Refer to EDID Management
(page 14) for more information on INT EDID mode.
Off AT-UHD-CAT-4 is set LEARN EDID mode.
LEARN Blue AT-UHD-CAT-4 is in “learn” mode. Refer to EDID Management (page 14)
for more information on LEARN EDID mode.
Flashing Blue AT-UHD-CAT-4 is in the process of learning the downstream EDID.
Off AT-UHD-CAT-4 is set to INT (internal EDID) mode.
