AT-UHD-CAT-2
28
Powering Sinks and the AT-UHD-CAT-2
Device Operation
In this mode, the POWER button will power-on / power-o the unit and the connected displays. CEC* power-on /
power-o commands are transmitted over both HDBaseT OUT ports.
1. Make the proper connections by following steps 1 through 4, under Powering Sink Devices (page 26).
2. Launch a web browser and login to the web server. Refer to Introduction to the Web Server (page 29) for more
information. The factory-default username and password are listed below:
Username: root
Password: Atlona
3. Click the Power button mode drop-down list and select Both.
4. Test the CEC power-on and power-o commands for the display (sink) device by pressing the ON and OFF
buttons, near the bottom of the page.
5. Press the POWER button on the front panel to power-on or power-o both the display and AT-UHD-CAT-2.
*Consumer Electronics Control (CEC): Atlona has conrmed proper CEC functionality with several current models of Samsung, Panasonic, and
Sony displays. However, it is not guaranteed that CEC will work with all displays. Many manufacturers do not support the CEC “o” command,
and older displays use proprietary commands. Atlona only supports displays that use the CEC command structure dened in HDMI 1.2a. It is
recommended that dealers request an evaluation product from Atlona, before designing a system using the CEC protocol. If this is not possible,
then other control methods will need to be considered, in order to control displays using Atlona products.
