AT-OMNI-121 / AT-OMNI-122
39
Basic Conguration Tutorial
• Verify that all encoders and decoders are set to the same system mode. In this tutorial, both encoders and the
decoder should be set to VCx. Refer to Setting the System Mode (page 27).
• Go to the IP Input menu and verify the following. Refer to Subscribing to an Encoder (page 33) for more
information.
» Under both the Input 1 and Input 2 window groups, verify that the Enable toggle switch is enabled.
» Check that the Multicast address eld is set to the correct multicast IP address. In this example,
226.0.0.1 for Input 1 and 226.0.0.2 for Input 2.
» Check that the Port eld is set to the proper port. In this example, 1000 for both Input 1 and Input 2.
» Under both the Input 3 and Input 4 windows groups, verify that the Enable toggle switch is enabled.
» Check that the Multicast address eld is set to the correct multicast IP address. In this example,
226.0.10.1 for Input 3 and 226.0.10.2 for Input 4.
» Check that the Port eld is set to 1100 for both Input 3 and Input 4.
• Go to the HDMI Output menu and verify the following. Refer to Subscribing to an Encoder (page 33) for more
information.
» Make sure that the Descrambling > Enable toggle switch is enabled.
» Check the HDCP > Version eld to make sure the correct version is selected. Also note the color of the
HDCP > Encrypted indicator. if it is red, then a picture may not be displayed and result in a “blue screen”
on the display. Change the HDCP > Version eld, if necessary.
IMPORTANT: The scrambling key on a decoder must be identical to the scrambling key on
the encoder which is being subscribed. Scrambling keys are case-sensitive.
Decoder Checklist
» Verify that the Descrambling > Key eld is set to scrambling.
» Make sure that the Video > Input drop-down list is set to one of the congured inputs: either ip_input1 or
ip_input2.
» Make sure that the Audio > Input drop-down list is set to one of the congured inputs: either ip_input3 or
ip_input4.
