Using OmniStream
™
with Velocity
™
Device Manager
60
Device Operation
Landscape Orientation
If any displays have been mounted upside-down, the orientation can be corrected, without having to remount the
displays in the correct orientation.
a. Click the Edit icon (pencil icon) in the upper-right corner of the display that requires adjustment.
b. The dialog for the selected decoder will be displayed.
c. Click the Rotation drop-down list and select the desired rotation. If the image on the display is upside-down,
select 180 degrees.
d. Click the CLOSE button to commit changes.
If any displays have been mounted upside-down, the orientation can be corrected, without having to remount the
displays in the correct orientation.
a. Click the Edit icon (pencil icon) in the upper-right corner of the display that requires adjustment.
b. The dialog for the selected decoder will be displayed.
c. Click the Rotation drop-down list and select the desired rotation. If the image needs to be rotated from
landscape to portrait, select 90 degrees. If the display is mounted upside-down AND requires rotation
from landscape to portrait, select 270 degrees.
d. Click the CLOSE button to commit changes.
Portrait Orientation
IMPORTANT: Portrait Mode is only supported on single-channel decoders.
Once Auto Arrange has been applied, the Pixel Space window will appear. It should be noted that each display
can be rearranged if necessary. To reposition displays, click and drag them to the appropriate places, within
the Pixel Space window. Note that each display is identied with a name and an IP address, in the upper-left
corner. Refer to the Velocity User Manual for more information on naming devices.
10. Click the Lock Displays icon in the menu bar of the Pixel Space window. This is optional. However, enabling
this feature will prevent accidental repositioning of the displays, during the conguration procedure. When
locked, this icon will turn red. Both the Trash and Auto Arrange icons will be disabled. To unlock the displays
(for adjustment purposes), click the Lock Displays icon again.
11. Click the Save icon in the upper-right corner of the Pixel Space window. This will save the current layout.
