Using OmniStream
™
with Velocity
™
Device Manager
56
Device Operation
Adding Subframes
Deleting a Subframe
Deleting a Multiview
Multiview supports a maximum of 4 subframes. As long as the maximum number of subframes is not exceeded,
additional subframes can be added. This provides for customization of existing layouts.
1. Click the MULTIVIEW menu.
2. Click the Available Multiview drop-down list to select the multiview to be changed.
3. Click the ADD SUBFRAME button.
4. The New Subframe dialog will be displayed.
5. Enter the title of the new subframe in the Name eld.
6. Click the Input drop-down list to select the desired input. Only a list of currently congured IP inputs will be
available from this list. If a new IP input is desired, it will need to be congured.
7. Enter the desired values in the X and Y elds, relative to the anchor point.
8. Click the Anchor drop-down list and select the desired anchor point.
9. Enter the z-order value in the z-order eld.
10. Click the SAVE button to commit changes.
1. Click the MULTIVIEW menu.
2. Click the Available Multiview drop-down list to select the multiview to be changed.
3. Under the name of the subframe (LEFT, RIGHT, TOP_LEFT, etc.), click the DELETE button. The subframe will
be immediately removed from the multiview.
1. Click the MULTIVIEW menu.
2. Click the Available Multiview drop-down list to select the multiview to be deleted.
3. Under the CONTAINER submenu, click the DELETE button.
IMPORTANT: In order to delete a Multiview, the Multiview to be deleted must not be in use by
the decoder. Click the HDMI OUTPUT menu, then click the Video > Input drop-down list to
select another IP input or a dierent Multiview.
Using Audio in Multiview
When using multiview, a decoder can only subscribe to a single audio stream. To use an audio stream in multiview,
simply congure the audio as part of the session (Audio > Source > hdmi_input1, for example). Refer to Creating
a Session (page 20) for more information.
