Using OmniStream
™
with Velocity
™
Device Manager
52
Multiview Conguration
1. Click MULTIVIEW in the menu bar.
2. Click the ADD NEW MULTIVIEW button.
3. The New Multiview dialog box will be displayed.
4. Enter a name for the multiview conguration in the Name eld. Since this decoder will be a picture-in-picture
layout, use the name multiviewpip.
The nal step is to congure the decoders to display the proper stream(s), as outlined in the tutorial diagram (shown
below).
AT-OMNI-111
AT-OMNI-121
PoE Network Switch
Laptop
Ethernet
Ethernet
Ethernet
Ethernet
HDMI IN
HDMI OUT
HDMI OUT
HDMI OUT
LAN
HDMI
PWR
LINK
TM
O
MNI
S
TREAM
ID
TM
O
MNI
S
TREAM
LINKPWR
AT-OMNI-121
Display
Display
Display
Ethernet
TM
O
MNI
S
TREAM
LINKPWR
AT-OMNI-121
Ethernet
TM
O
MNI
S
TREAM
LINKPWR
AT-OMNI-111
HDMI IN
HDMI
PWR
LINK
TM
O
MNI
S
TREAM
ID
HD camera
4K
4K
720p
1080p 1080p
1
0
X
Z
o
o
m
F
1
.
6
-
F
3
.
0
f
4
.
7
m
m
-
f
4
7
m
m
1
0
X
Z
o
o
m
F
1
.
6
-
F
3
.
0
-
f
4
7
m
m
4K + 1080p
1080p + 720p
Encoder #1
Encoder #2
Decoder #1
Display #1
Display #2
Display #3
Decoder #3
Decoder #2
Decoder #1
5. Click the Resolution drop-down list and select 3840x2160.
6. Click the Layout drop-down list to view the available layouts, and select pip-bottom-right.
7. Click the main (3840x2160) drop-down list and select IP Input 3 - 226.0.0.3:1000.
8. Click the bottom_right (1280x720) drop-down list and select IP Input 2 - 226.0.0.2:1000.
Device Operation
NOTE: Multiple multiview congurations can be created and saved. To display a dierent
multiview, go to the HDMI Output menu, locate the Video section and click the Input drop-
down list to select the desired multiview conguraiton.
