Using OmniStream
™
with Velocity
™
Device Manager
51
IP Input 1 - 226.0.0.1:1000
IP Input 2 - 226.0.0.2:1000
IP Input 3 - 226.0.0.3:1000
IP Input 4 - 226.0.0.4:1000
1. Go the the decoder and click IP INPUT in the menu bar.
2. Congure the following elds, under each IP Input window group, as follows:
Decoder Conguration
IP Input Multicast Address Port
IP Input 1
226.0.0.1 1000
IP Input 2
226.0.0.2 1000
IP Input 3
226.0.0.3 1000
IP Input 4
226.0.0.4 1000
3. Click the Enabled toggle switch for each IP Input window group. When enabled, the toggle switch will be green.
4. Click SAVE, under each IP Input window group, to commit changes.
5. Click the HDMI OUTPUT menu.
6. Verify that each source can be displayed, independently. To do this, locate the Video section and click the Video
drop-down list. Alternate between the following selections to display each source.
If any of these sources are not displayed, return to the encoder IP INPUT, SESSION, and ENCODING menus to
verify that the conguration is correct.
Decoder #1, Decoder #2, and Decoder #3
Encoder #1 (source: HD camera)
Encoder #2 (source: Laptop)
Dual-streaming has been successfully congured on both encoders. This provides a total of four streams which are
listed in the tables, below, for reference.
The next step is to congure each decoder to subscribe to these streams. Although, in the tutorial diagram, each
decoder is subscribed to no more than two streams, we will congure all three decoders to access all four streams.
This will allow us to change the output on the displays, if desired.
Device Operation
Stream Encoder Resolution Stream Multicast IP Address Port
1 Encoder 1
1920x1080
Stream 1
226.0.0.1 1000
2 Encoder 2
1280x720
Stream 2
226.0.0.2 1000
Stream Encoder Resolution Stream Multicast IP Address Port
3 Encoder 1
3840x2160
Stream 1
226.0.0.3 1000
4 Encoder 2
1920x1080
Stream 2
226.0.0.4 1000
