Using OmniStream
™
with Velocity
™
Device Manager
11
DEFINITIONS
Stream – Describes the video, audio, or any data that is transmitted from an encoder over the
network.
Multicast IP Address – A class-D IP address assigned to a stream.
UDP Port – User Datagram Protocol (UDP) port. Part of the network addressing scheme to send
and receive data to the proper destination on a network.
Subscribing – The process of selecting the multicast IP address to “listen to”, in order to receive
one or more encoder streams at the decoder endpoint.
Introduction to OmniStream
OmniStream Naming Schema
Each OmniStream model has a dierent set of inputs and outputs and, depending upon the number of inputs and
outputs. The number of supported session will depend upon the encoder model.
The last three numbers of the OmniStream SKU, describe the model version, model type, and number of outputs.
Note that the number of Ethernet outputs is the same as the number of HDMI inputs.
• AT-OMNI-112 1= OmniStream Pro (“R-Type” models begin with the number “5”).
1 = Indicates that the device is an encoder (decoders are identied with the number “2”).
2 = The number of Ethernet outputs.
Encoders Description
AT-OMNI-111
AT-OMNI-111-WP
• One HDMI input
• One Ethernet output
• Supports up to six sessions
AT-OMNI-112 • Two HDMI inputs
• Two Ethernet outputs
• Supports up to six sessions
AT-OMNI-512 • One HDMI input
• One Ethernet output
• Supports up to four sessions
Decoders Description
AT-OMNI-121 • One HDMI output
• One Ethernet output
AT-OMNI-122 • Two HDMI inputs
• Two Ethernet outputs
