AT-HDVS-200-TX / AT-HDVS-200-TX-PSK
10
Installation
IP Conguration
The AT-HDVS-200-TX is shipped with DHCP enabled. Once connected to a network, the DHCP server (if available),
will automatically assign an IP address to the unit. Use an IP scanner, along with the MAC address on the bottom of
the unit, to identify both the unit and its IP address on the network. If a static IP address is desired, the unit can be
switched to static IP mode. Use one of the following procedures to switch between DHCP and static IP mode.
The default static IP address of the AT-HDVS-200-TX is 192.168.1.254.
Use the IPStatic and IPDHCP commands to switch between DHCP and IP mode through RS-232 or Telnet. Refer to
Commands (page 3), for more information. All commands and their arguments are case-sensitive.
Using the Front Panel
Using Commands
1. Make sure the AT-HDVS-200-TX is powered.
2. Press and hold the INPUT button for approximately 15 seconds.
• Setting static IP mode
1. Connect to the AT-HDVS-200-TX using RS-232 or Telnet.
2. At the command line, execute the IPDHCP command using the o argument, as shown.
IPDHCP o
3. Execute the IPStatic command. This command requires three arguments: the desired IP address of the AT-
HDVS-200-TX, the subnet mask, and the gateway address. All arguments must be entered in dot-decimal
notation. The following is an example:
IPStatic 192.168.1.112 255.255.255.0 192.168.1.1
3. Release the INPUT button once the PW LED indicator begins to ash. The number of ashes will indicate the
currently selected IP mode.
HDMI IN 2
RS-232
RX
RL
TX
PW
HDMI
INPUT
DISPLAY
v
v
AT-HDVS-200-TX
VOL
HDMI IN 1 VGA IN AUDIO IN
1
2
VGA
FW RS-232
HDMI IN 2
LAN HDBaseT OUT
RS-232
RX
TX
PW LED indicator
PW LED ashes Description
Two Static IP mode
Four DHCP mode
