– 15 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual
ECM-15SH
AC
Power Conditioner & Suppression Module
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
ECM-15SH Specifications
Type AC Power Conditioner Suppression Module
RoHS Compliant Yes
Safety Listings ETL (UL 60065 Standard)
Front Panel
Outlets Two, 15A
Indicators Active (Green), Fault (Red), Incoming AC (Red)
Manual Override Slide Switch
Connectors 5 Position Phoenix Euro Block Style
Hard Switch Remote Trigger SPST Contact
Status Signals Output for Voltage and Current Data (All data signals are low voltage and current)
Spike & Surge Suppression H-N, N-G, H-G
Fuse Protection 15A Slow Blow
Power Cord 9ft (3m), 14 gauge
Technical Data
Current Rating 15A
Operating Voltage 102VAC - 132VAC
Power Consumption 500 milliwatts
Power Requirements 120V 60Hz
Extreme Voltage Shutdown (EVS) Below 102V or above 132V AC Line (When used with ECS-6RM)
DCV Remote Trigger 5-24DCV
High Voltage Surge Protection Trigger at 133VAC, 1ms typically (When used with ECS-6RM)
Low Voltage Surge Protection Trigger at 101VAC, 1ms typically (When used with ECS-6RM)
Spike and Surge Suppression Hot to Neutral, Hot to Ground, Neutral to Ground
Spike Protection Modes Circuitry on Incoming AC Mains
Min. Spike Clamping Voltage 460 VRMS @ 3,000 amps
Max. Spike Clamping Voltage 6kV
Max. Spike Clamping Resp. Time <1 nanosecond
Spike Clamping Voltage @ 100A 1,250Vp for 20µs
Maximum Surge Current 6,500A
Energy Rating 600 Joules
Noise Attenuation EMI/RFI Sequencer 10dB @ 10 kHz, 40dB @ 100 kHz, 100dB @ 10MHz
Temperature Range 5° – 35°C
Humidity Range 5% to 95% R.H.
Mechanical
Chassis Finish Black
Mounting Side Bracket Adjustable
Height 1.75" (45mm)
Width 8.5" (216mm)
Length 5.0" (127mm)
Weight 4.5 lbs (2.04kg)
