AtlasSound.com – 14 –
ECM-15SH
AC
Power Conditioner & Suppression Module
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
AC Power Cord Retainer System
4. Wrap the zip tie around the power cord as shown in Figure 4.
5. Feed the end of the zip tie through the retainer and pull tightly
to secure. Note: Some adjustment of the retainer may be
needed in order to properly align it as shown in Figure 6.
6. Cut the excess zip tie off as shown in Figure 7.
Your Atlas Power product comes with an AC Mains Power Cord Retainer System. This system prevents the power cord
from being removed without the use of a screwdriver. Follow these steps for installation.
Note: Installation of this product must be done by a certified electrician for a permanently connected apparatus provided
neither with an all-pole mains switch nor an all-pole circuit breaker. A readily accessible disconnect device shall be
incorporated in the building installation power wiring. The installation shall be carried out in accordance with all applicable
installation rules in accordance with all applicable federal, state, and local laws, regulations, safety codes and ordinances.
1. Locate the 6/32 screw, retainer clip, and zip tie.
2. Locate the AC wall outlet that will be used to power the
Atlas Power product. Remove the center screw securing the
cover plate to the AC outlet.
3. Place the screw through the retainer clip and insert into the
cover plate making sure to securely tighten. Inset the zip tie
through the retainer clip slots as shown in Figure 3.
Figure 1
Figure 5 Figure 6
Figure 7
Figure 4
Figure 2 Figure 3
