OWNER’S MANUAL

AC POWER DISTRIBUTION & SURGE SUPPRESSOR UNIT

AP-S20

INSTALLATION

Before installing, read the entire manual to ensure proper understanding of operation and that all features are being utilized. The AP-S20 can be placed on a shelf or rack

mounted in a standard 19” width rack. When rack mounted, placement within the rack is flexible, however the AP-S20 should be within 6’ of a dedicated 20A AC outlet.

When rack mounting, use rack rail type screws of 10/32” x 1”. Always make sure the 20A outlet is properly inspected by a certied electrician prior to connecting the

AP-S20. Make sure to inspect the equipment that will be connected to the AP-S20 to ensure it does not exceed 20A total amperage draw.

AUDIO SPECIFICATIONS / PERFORMANCE

System

Model AP-S20

Type AC Power Distribution & Surge Suppressor

Load Rating 20A

Safety Listings UL 60950-1 Standard

Front Panel

Outlets 1 Unswitched, Note: All Outlets are Surge and RF Protected

Activation Switch Rocker, Illuminates Red when in the ON position

Indicators AC Power ON (Red), AC Protect Active ON (Green)

AC Mains Circuit Breaker 20A Resettable

Rear Panel

AC Outlets NEMA 5-20R, 8 Outlets Total: 7 Switched, 1 Unswitched

AC Mains Power Cord 9' (2.74m), 12 Gauge, AC Plug NEMA 5-20P

Technical

Current Rating Limited to 16A 2000W Continuous

Current Protection 20A AC Mains Breaker

Operating Voltage 102VAC – 132VAC

MOV - New Generation Qty. 3 Hot to Neutral, Hot to Ground, Neutral to Ground

Clamping Voltage L-N: 400, L-G: 500, N-G: 400 / 3KA, 8/20μs

Max. Spike Clamping Voltage 6kV, 1.2/50μs

Max. Spike Clamping Resp.

Time

<1 nanosecond

Maximum Surge Current 45000A, 8/20μs

Energy Rating @ 2ms 900 Joules, 8/20μs

Noise Attenuation RFI 40dB @ 10kHz - 100MHz

Temperature Range 5° to 35°C

Humidity Range 5% to 95% Relative Humidity

Mechanical

Color Black

Rack Mount Requirements 1 RU, 19"

(CONTINUES ON NEXT PAGE)
