AP-S15HRIP / AP-S15IP / AP-S158IP
Owner’s Manual
– 23 –
AtlasIED.com
TELEPHONE: (800) 876-3333
SUPPORT@ATLASIED.COM
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
Alarm Settings WEB Page
1. Alarm Page is selected.
2. Save Button - Make sure to select this after every change or the new setting will not be applied.
3. Temp Alarm Enabled Button
• When this box is checked the temperature alarm settings are engaged.
• Select Save.
• On the Status Page the indicator will reflect the alarm is enabled.
4. Temp Alarm Settings
• Enter the value for the Temp Alarm to trigger. The operating range is 50° - 176°F, 10° - 80°C
• Select Save.
• If the alarms are activated the GUI and front panel indicators will turn red until the values are within safe operating range.
• The fault reason, day and time will be recorded in the Alarm Activation log section located at the bottom of the Alarm page.
• The fault control port contact relay will be open when any alarm is activated.
5. Humidity Alarm Enabled Button
• When this box is checked the humidity alarm settings are engaged.
• Select Save.
• On the Status page the indicator will reflect the alarm is enabled.
1
2
3
4
5
6
8
9
11
12
7
10
