Chapter 1. Introduction
13
5 power & status LEDs
Power: Lights green to indicate the unit is receiving
power and turned on.
Remote / Local: Lights green to indicate which side
of the installation (Local or Remote) currently has
KVM control of the computer.
Rear View
6 grounding terminal The wire used to ground the unit connects here.
7 DC power jacks The cable from the DC power adapter connects here.
8 audio ports (console) These mini stereo ports are for the local speakers
(green) and microphone (pink).
9 RS-232 serial device
port
This RS-232 serial port is for connecting to a serial
terminal.
10 SFP+ slots The 10 Gigabit Ethernet (10 GbE) optical fiber cable
that connects the unit to the LAN plugs in here.
Note: The SFP+ slot supports 10GBASE-R
technology only.
11 10 Gb LAN port The cable that connects the unit to the LAN plugs in
here.
Note: The 10 Gb LAN port supports 1G / 2.5G / 5G /
10G NBASE-T technology.
12 console ports
USB: The unit’s USB keyboard and USB mouse
plug into these ports.
Video: The cable from the local DisplayPort monitor
plugs in here.
13 function switch Use this slide switch to set the unit’s mode to:
Auto: Shared (simultaneous) KVM control of the
computer at the Transmitter and Receiver console.*
If the auto mode is selected, the EDID mode will be
automatically applied to a pre-configured setting in
the basic transmitter configuration, see page Basic,
page 113.
RS-232 Config/Access Control: The device is
ready to be configured via serial commands through
the RS-232 port. When connected to a KVM over IP
Access Control Box (2XRT-0015G), users can
enable / disable control privileges of the connected
receivers.
Local: Only the local Transmitter has KVM control
of the computer. The Receiver’s KVM access to the
computer is locked. If local mode is selected, the
EDID of the Tx local console will be used.
In Auto mode, RS-232 and audio functions will work on
the Receiver but not on the Transmitter.
