CN9000/CN9600/CN9850/CN9950 User Manual
22
Installation
Follow the steps below and refer to the diagram on the following page (the
steps and the numbers correspond to each other) to install.
1. Connect the unit’s grounding terminal to a suitable grounded object.
2. Plug your keyboard, mouse, monitor display, speakers and microphone
into the local console ports on the rear panel.
3. Using the KVM cable provided, connect the unit’s PC/KVM and audio
ports to the keyboard, video, mouse, speakers and microphone ports of the
server or KVM switch that you are installing.
Note: For CN9600, CN9850, and CN9950, make sure the connected
computer’ video source is not HDCP encrypted to avoid blank
screen or screen flickering.
4. (Optional) If you wish to access locally using the laptop USB console
(LUC) function, use the USB Type-A to USB Mini-B cable provided to
connect a USB port of the laptop to this (LUC)
port.
Make sure you have set the mode in USB IO Setting to LUC. See p. 78.
5. (Optional) If you are using serial devices (data terminal equipment), such
as a touch panel, connect it to the local console COM (RS-232 DCE) port
with a network switch console cable.
6. (Optional) If you are using serial devices (data communication
equipment), such as a PC, connect it to the CPU COM (RS-232 DTE) port
with a serial RS-232 DB-9 to RJ-45 Cat5 Ethernet adapter network
modem/switch/router cable.
7. Plug a network cable into one of the unit’s LAN ports.
8. (Optional) Plug a second network cable into the other LAN port for dual
LAN operation.
9. (Optional) For CN9000/CN9850/CN9950, connect the NC and C
terminals to the server or PC for remote reboot operation.
10. (Optional) For CN9000/CN9850/CN9950, connect the GND and DI
terminals to an input device (e.g. thermometer, humidity sensor) for digital
input notification.
