CN9000/CN9600/CN9850/CN9950 User Manual
18
2 power jacks Plug the power adapter provided into an AC power
source, then plug the power adapter cable into any
power jack.
Plug a second power adapter into another AC power
source, then plug the power cable into the unit’s other
power jack.
Note: Dual power operation is optional — the second
power source is for backup; a second power adapter
requires a separate purchase.
3 control terminal
Connect the NC and C terminals to the PC / server
for remote reboot.
Connect the GND and DI terminals to an input
device (e.g. thermometer, humidity sensor) for digi-
tal input notification.
Note: When the input device’s monitoring parameter
(e.g. temperature, humidity) exceeds the set threshold,
1 is sent to the unit, otherwise, 0 is sent.
4 LAN ports Connect a Cat 5e/6 network cable to these ports for
uplink connection.
5 local console ports Connect the cables for the local console (USB
keyboard, HDMI monitor, USB mouse, microphone
and speakers) to these ports. Each connector is color
coded and marked with an icon.
